Osnovne karakteristike
|
Procesorsko ležište (socket): Intel 1851, Čipset: Intel Z890,
|
Memorija
|
Tip memorije: DDR5, Memorijski slotovi: 4, Podržane memorije: 8.666+MT/s (O.C.), Maksimalna ukupna memorija: 256GB, Ostale osobine: Podrška za Unbuffered ECC memoriju, Podrška za Extreme Memory Profile (XMP), Podrška za non-ECC UDIMM memory, ASUS Enhanced Memory Profile III (AEMP III), Podrška za CUDIMM,
|
Slotovi
|
PCI Express x16 slot: 1x PCI Express 5.0, 1x PCI Express 4.0 (x4 mode), 2x PCI Express 4.0 (x1 mode),
|
Skladišni interfejs
|
SATA priključci (ukupno): 6, SATA priključci: SATA III 6Gbps, Broj M.2 slotova: 3, Podržani M.2 formati: 2x 2280 (podrška za PCIe 4.0 x4 mod), 1x 2280 (podrška za PCIe 5.0 x4 mod), RAID: RAID 0, RAID 1, RAID 5, RAID 10,
|
Mreža
|
Žična mreža (LAN): 2.5GBase-T (Gigabit), Model: Realtek, Wi-Fi: Da, Wi-Fi standard: Wi-Fi 7 (802.11be), Bluetooth: Da, Bluetooth verzija: 5.4,
|
Audio
|
Broj kanala: 8 (7.1), Model: Realtek, Napomena: High Definition, PCB izolacija, Audio Shielding, Premium audio capacitors,
|
Priključci na zadnjem panelu
|
Broj DisplayPort priključaka: 1, DisplayPort priključci: 1x DisplayPort 1.4, Broj HDMI priključaka: 1, HDMI priključci: 1x HDMI 2.1, Ukupno USB priključaka: 8, Ukupno USB-C priključaka: 1, USB-A priključci: 2x USB 2.0, 4x USB 5Gbps (3.2 Gen 1), 1x USB 10Gbps (3.2 Gen 2), USB-C priključci: 1x USB 20Gbps (3.2 Gen 2x2), RJ-45 (LAN): 1, Audio: 3x 3.5mm, Ostali priključci: 1x Wi-Fi Module,
|
Unutrašnji priključci
|
Naponski priključci: 1 x 24 pin Main Power connector, 1 x 8-pin +12V CPU Power connectors, 1 x 4-pin +12V CPU Power connectors, USB-A: 1 x podrška za 2 USB 5Gbps porta, 2 x podrška za 4 USB 2.0 porta, USB-C: 1 x podrška za 1 USB 5Gbps port, Audio: 1x Front panel header, Ostali priključci: 1 x S/PDIF Out header, 1 x 4-pin AIO Pump header, 1 x 4-pin CPU OPT Fan header, 1 x 10-1 pin System Panel header, 1 x 4-pin CPU Fan header, 1 x 14-1 pin SPI TPM header, 1 x Clear CMOS header, 4 x 4-pin Chassis Fan headers, 1 x COM Port header, 1 x AURA RGB header, 1 x Thunderbolt™ (USB4®) header, 1x Chassis Intrusion Header, 3x Addressable Gen 2 headers,
|
Ostale karakteristike
|
Podržane tehnologije: AURA Sync, DIGI+VRM, LANGuard, Overvoltage Protection, SafeSlot, Q-DIMM, Q-Slot, Q-LED Core, ProCool, VRM heatsink design, Aura RGB header, BIOS FlashBack button, BIOS FlashBack LED, Stainless-Steel Back I/O, Q-Antenna,
|
Fizičke karakteristike
|
Format: microATX, Dimenzije: 244mm x 244mm,
|
Reklamacioni period
|
Reklamacioni period: 36 meseci,
|
